Beskrivning
Art.nr: JEX-MF2G-800
Description
The MFlow2 Gas 800 is a telemetry sensor that measures the flow of the pumped fuel and calculates its amount in the tank. The MFlow2-Gasoline is a variant for the models powered by glow or gasoline motors.
Main features
- The sensor is compatible with Duplex EX system.
- EX telemetry values: actual flow and the amount of the fuel in the tank.
- User adjustable parameters, such as tank capacity, depleted fuel alarm, etc.
- Firmware updates.
MFlow2 consists of the flow sensor and the base. The sensor is connected to the base via a cable with a lock connector. The other cable labeled as „Ext“ is used for the DUPLEX system or the JETIBOX. The flow sensor is fitted with these endings according to the type:
MFlow2 G: 2x barbed fittings for tubes with the internal diameter of 2 mm a 2x barbed fittings for tubes with the internal diameter of 3 mm
Parameters
| Weight [g] | 40 |
|---|---|
| Dimensions [mm] | 72 x 41 x 30 |
| Operational temperature [°C] | -20 to 80 |
| Supply Voltage [V] | 5 to 8.4 |
| Average Current [mA] | 20 |
| Measurement range | 20-800 ml/min |
| Measurement accuracy | ±2% |
| Tubing connection | 2x barbed fittings Ø2 a Ø3 |
